創鈺提供「UWB」與「BLE」定位導航技術實際應用於各大醫院、製造業與博物館等領域可依「儀器、人員定位」或「室內導航定位」需求提供合適的解決方案。
  • 智慧醫療
  • 智慧工廠
智慧醫療解決方案:BLE 定位導航、UWB 儀器/人員定位
Beacon 智慧醫療導診
問題:

民眾就診找不到診間? 排隊時間過長?

解答:

Beacon 智慧醫療導診

將 Beacon 導航功能整合院內 HIS 系統,提高患者就診速度,降低院內交叉感染風險。

UWB + Tag &電子圍籬
問題:

如何有效管理重症患者?

解答:

UWB + Tag &電子圍籬

重症患者或特殊病患(精神病、憂鬱症患者等)佩戴 UWB Tag,可隨時了解患者位置、移動軌跡,可對病患活動區域進行電子圍籬告警,一旦有緊急情況發生,可第一時間找到病患。

當患者卸下 UWB Tag,系統會警示醫護人員。

UWB + Tag 外包人員管理與調度
問題:

如何保障醫護人員安全?無法有效調度外包人員?

解答:

UWB + Tag 外包人員管理與調度

可數據化記錄工作內容、活動軌跡與停留時間;另外也可對保全進行定位追蹤,查看是否在崗,提高管理效率,準確獲得每個區域的保全人員訊息,在發生意外的第一時間能夠就近調派保全人員前往處理。

UWB + Tag 貴重醫療儀器定位盤點
問題:

急診中心、開刀房、護理站的儀器盤點?

解答:

UWB + Tag 貴重醫療儀器定位盤點

醫護人員可透過圖台立即查看所需儀器位置;並進行自動盤點作業管理人員可透過系統查看各儀器詳細使用數據,提高閒置儀器使用率,實現儀器目視化管理。

UWB + Tag 智慧健檢
問題:

如何提高健檢效率?

解答:

UWB + Tag 智慧健檢

只要讓健檢貴賓配戴 UWB Tag,院內服務員透過管理 App 可即時掌握貴賓位置,通知貴賓回健檢室進行檢查。

智慧工廠解決方案:UWB 儀器/人員定位
問題:

場域寛闊,進出人員管理棘手
特殊廠房或存放重要設備區域難以管控
巡檢數據無法有效分析

解答:

UWB 室內定位解決工廠5大問題

充分考慮工廠生產管理5大要素,有效控管工安風險、提升產值與效率,並進一步整合其他資訊系統。

智慧工廠解決方案:UWB 儀器/人員定位

人員:
  1. 特定區域人員出入警示:

    圖台可顯示配戴 Tag 人員即時位置,針對危險區或重要區設置電子圍籬,承包商一旦超越規定範圍即自動通報。

  2. 緊急求救:

    當人員按 Tag 求救鈕,圖台顯示求救者即時位置,並通知救護人員。另當 Tag 偵測墜落或靜止不動,系統亦自動通報。

  3. 提升員工效值:

    查看當前位置、是否在崗、工作時長度等數據,從而優化員工作業流程,提高工作效率。

  4. 數據統計:

    圖台可查看外來訪客的進出時間、並調出移動軌跡等數據。

機器:
  1. 設備定位管理:

    後台可查看移動設備的即時位置,方便即時調用,可設置電子圍籬,一旦超出警戒區域會發出警報。

  2. 其他系統整合:

    圖台系統可整合產線主要機器設備的位置與產能狀態,當設備故障或需要更換零件時,主動通報管理者與相關人員,讓產線能正常運作。

物料:

物料配送監控:

圖台可查自走車起始位置、運動軌跡,實現智能化調度管控,當發生碰撞、脫離軌道等異常現象而靜止不動時,圖台會亮起警示燈,中控室會告知人員前往處理。

方法:

提高生產效率與產品良率:

圖台整合生產資訊管理系統,如發生產品良率低於正常標準時,管理者可透過圖台上的即時監控影像功能,確認產線狀況。

環境:

關燈工廠應用:

圖台系統可對接工廠節能系統,依照區域人員多寡調整該區域燈光、空調。

監視器系統整:

圖台系統整合既有之監視器設備,可能配合監視器第一時間了解人員移動設計之狀況。

產品規格
Product Specification

人員定位標籤 People Tag

UWB & BLE ( iBeacon|Mesh )
Protocol Options
  • Beacon
    YES
  • UWB
    YES
  • Trigger Click
    Yes
  • Range
    Up to 100 meters
  • Antenna
    PCB
  • Transmission Interval
    From 100ms to 1000ms
  • Transmission Power
    -12dbm, -8 dbm, -4 dbm, 0 dbm,4 dbm
  • Capacity
    1200mAh
  • Replaceable
    No
  • Warranty
    1 years
  • Color
    White|Black
  • Chipset
    Nordic nRF52832
  • Button
    Reset
  • Custom housing available
    Vibration, Buzzer
  • Size
    40 mm x 34 mm x 10.4 mm
  • Operating environment
    0 ~ 80
  • Operating Voltage
    5V
  • Operating current
    100mAh
  • Operating frequency
    UWB 6.5GHz
    BLE 2.5GHz
Ci - BLE ( iBeacon|Mesh )
Specification
  • Device name
    Bluetooth Mesh/Beacon
  • Brand
    Creatidea Inc.
  • Model No.
    Ci - BLE MESH
  • Manufacturer
    Creatidea Inc.
  • Equipment type
    BLE
  • Frequency of operation
    2402-2480MHz
  • Channel Spacing
    2MHz
  • Channel Number
    40 channels
  • Type of modulation
    GFSK
  • Data Transmission Rate
    1M bps
  • Operating voltage
    External 5V supply or Internal 3.7V battery
  • Beacon Operation Time
    1 month using 1300mAH/3.7V battery
  • Antenna Type
    Chip Antenna
  • Antenna Gain
    0 dBi
  • Output power
    -8 dBm
Ci - B1
Protocol Options
  • iBeacon
    Yes
  • Eddystone
    Yes
Other Option
  • Power Amplifier
    Yes
Features
  • Super-long range
    The max. 500m with PA (in open space)
  • Battery lifetime
    Up to 10 years (default setting)
  • Waterproof grade
    IP67 waterproof grade
Battery
  • Model
    AA batteries
  • Capacity
    2900mAh
  • Replaceable
    Yes
  • Operating Temperature
    -20°C to +70°C (Battery limit)
Service
  • Warranty
    12 months
Radio
  • Bluetooth
    Bluetooth low energy 5.0 compatible
  • Transmission Interval
    From 100ms to 5000ms
  • Transmission Power
    -40dBm, -20dBm, -16dBm, -12dBm, -8dBm, -4dBm, 0dBm, 5dBm
  • Antenna
    PCB antenna
Construction
  • Material
    ABS plastic housing
  • Dimensions
    72*72*18mm
  • Weight
    109g
  • Chipset
    nRF52
  • Color
    White, Black (Other colors can be customized)
  • Accessories
    1pc double-sided adhesive
Product Compliance
  • Certification
    CE, FCC, Bluetooth QDID/EPL
Ci - B2
Protocol Options
  • iBeacon
    YES
  • Eddystone
    YES
Radio
  • Bluetooth
    Bluetooth low energy 5.0 compatible
  • Range
    Up to 100 meters
  • Antenna
    PCB antenna
  • Transmition Interval
    From 100ms to 5000ms
  • Transmit Power:
    -40dBm, -20dBm, -16dBm ,-12dBm, -8dBm, -4dBm, 0dBm, 4dBm
Battery
  • Model
    ER14250
  • Capacity
    2400mAh
  • Replaceable
    Yes
  • Operating Temperature
    -40°C to +70°C (Battery limit)
Product Compliance
  • Certification
    CE, FCC, Bluetooth QDID/EPL
Service
  • Warranty
    1 year
Construction
  • Material
    ABS plastic housing
  • Dimensions
    Φ50*20.5mm
  • Weight
    39.5g
  • Color
    White
  • Chipset
    Bluetooth 5.0 chipset nRF52 series
Features
  • Button
    Internal power ON/OFF push button
  • Waterproof grade
    IP65 waterproof grade
  • Case
    Smart rotatable mechanical design for the case
  • Custom housing available
    Yes
Ci - B3
Protocol Options
  • iBeacon
    YES
  • Eddystone
    YES
Sensor Option
  • Accelerometer Sensor
    YES
Features
  • ON/OFF button
    External push button
  • Installation method
    Double-sided adhesive
  • Waterproof grade
    IP65 waterproof grade
Battery
  • Model
    CR2477
  • Capacity
    1,000mAh
  • Operating Temperature
    -20°C to +70°C (Battery limit)
  • Battery life (Tx=0dBm; Interval: 900ms)
    Up to 2 years
Service
  • Warranty
    12 months
Radio
  • Bluetooth
    Bluetooth low energy 5.0 compatible
  • Transmission Interval
    From 100ms to 5000ms
  • Transmission Power
    -40dBm, -20dBm, -16dBm, -12dBm, -8dBm, -4dBm, 0dBm, 4dBm
  • Range
    100 meters
Construction
  • Material
    ABS plastic housing
  • Dimensions
    Φ50 x 15mm
  • Weight
    80g
  • Chipset
    nRF52
  • Color
    White (Other colors can be customized)
  • Accessories
    1pc double-sided adhesive
Product Compliance
  • Certification
    CE, FCC, Bluetooth QDID/EPL
Ci - S00 單向
Protocol Options
  • iBeacon
    YES
  • Eddystone
    YES
  • Trigger Click
    Yes
Features
  • Elegant Design
    Portable with key chain hole
  • Key Fob Button
    Programmable with 3 kinds of trigger click option
  • Easy to Print Logo
    Onto the case or package gift
Compatibility
  • Wireless Compatibility
    Bluetooth low-energy 4.1and 5.0
  • Compatible Systems
    iOS 7.0 or above, Android 4.3 or above
  • Protocols
    iBeacon, Eddystone (UID, URL, TLM)
Physical Character
  • Color
    White, Other colors can be customized
  • Dimensions
    Diameter 35 x 8.2 mm
  • Weight
    7 g
  • Battery
    One replaceable, CR2025
Radio
  • Beacon Interval
    Configurable 100ms to 5 second
  • Transmit Power
    - 40dBm to 4dBm Configurable
  • Signal Range
    50 meters
Verification
  • Estimated Operational Life
    8 months with a 900ms 0dBm ibeacon interval
  • Environment Resistance
    Indoor environment, shock resistant
  • Regulatory
    iBeacon MFi License, CE, FCC, Bluetooth QDID/EPL
Ci - S01 單向
Specification
  • Technology
    iBeacon/LORA
  • Chip
    SiliconLab Flex Gecko (64 MHz Cortex-M4 with FPU)
  • Usage time
    6 month, 10hr / day Transfer once in 5.5 seconds
  • Resolution
    1.5m ~ 3m
  • Transmission Distance
    70m
  • Battery
    380mAh 1pc
  • Charging port
    Magnetic
  • Three axis sensor
    1pc
  • Optional
    Vibration
  • Expansion
    Can be matched with indoor positioning system
Ci - S02 單向
Protocol
  • Standard iBeacon
    Yes
Radio
  • Bluetooth
    Bluetooth low energy 4.0
  • Antenna
    PCB antenna
  • Transmit interval
    Configurable 100ms to 10s
  • Transmit power
    -30dBm, -20dBm,-16dBm, -12dBm, -8dBm, -4dBm,0dBm,4dBm
  • Additional configuration options
    0 Connectable, configuration mode; 1 Non-connectable, deployment mode.
  • Range
    Up to 30 meters
Battery
  • Model
    CR2032
  • Capacity
    225mAh
  • Operating Temperature
    -20°C to +60°C (Battery limit)
  • Expected life
    8.5 months by default
Service
  • Warranty
    1 year
Construction
  • Material
    ABS plastic housing
  • Dimensions
    36.2*26.1*7.2mm
  • Weight
    7.0g
  • Color
    White
Features
  • Wristband
    Disposable detachable wristband
  • Waterproof grade
    IP66
  • Power on/off
    Magnetic switch
Ci - S03 單向
Protocol Options
  • iBeacon
    YES
  • Eddystone
    YES
Advertising
  • Advertising interval
    From 100ms to 5000ms
  • Tx power
    -40dBm, -20dBm, -16dBm, -12dBm, -8dBm, -4dBm, 0dBm, 4dBm
  • Additional configuration options
    Configure mode; Non-connectable mode
Radio
  • Version
    Bluetooth low energy 5.0
  • Frequency
    2.4GHz
  • Chipset
    nRF52
  • Antenna
    PCB antenna
  • Range
    Up to 90 meters
Enclosure
  • Material
    ABS plastic housing
  • Color
    White(custom color and logo are available on demand)
  • Size
    φ35.9*11mm
  • Weight
    12.0g
Battery
  • Replaceable
    Yes
  • Model
    CR2032(220mAh)
  • Expected life
    Up to 1 year
Features
  • Accelerometer sensor
    Optional
  • NFC
    Wristband with built-in 13.56MHz NFC
  • Waterproof
    IP66
  • Wristband
    Detachable
Ci - S04 單向
Bluetooth
  • Bluetooth low energy 5.0
Data Storage
  • 20,000 contact records
Vibration/Light Alert
  • Triggered when another tag intrudes 2m/6ft safe distance
Operating Temperature
  • -20°C to +60°C
Input Voltage
  • DC 5V
Battery Type
  • Rechargeable Lithium Battery
Charge Method
  • Direct USB charging
Charging Time
  • 2H
Pre-installed package for App development
  • Available
SDK
  • Available
Construction
  • Material
    Main body: ABS+PC; Strap: TPU
  • Length
    26cm
  • Weight
    24.5g
  • Color
    Black
  • Build-in Sensor
    ACC
Features
  • Wristband
    Social distancing wristband
  • Waterproof grade
    IP67
  • Power on
    Touch button
Ci - S05 單向
Specification
  • Advertising iBeacon & Eddystone & Sensor data
  • Unique MAC address (ITU)
  • Bluetooth 5.0 chipset nRF52 series
  • Low power consumption 3-axis accelerometer
  • Included 1pc CR2032 coin battery replaceable
  • The max. 50 meters advertising distance
  • Weatherproof housing with key-chain hole
  • Case Color
    white
  • Battery Model
    CR2032
  • Operation Voltage
    1.8-3.6V
  • Transmission Current
    5.3mA (peak current)
  • Transmission Range
    50 meters
  • Sampling Interval
    900ms
  • Antenna
    50ohm
  • Sampling Accuracy
    +/- 2g
  • Size
    43 x 43 x 21mm
Ci - S06 單向
Protocol
  • Standard iBeacon
    Yes
Radio
  • Bluetooth
    Bluetooth low energy 5.0
  • Antenna
    PCB antenna
  • Transmit interval
    Configurable 100ms to 10s
  • Transmit power
    -20dBm~+4dBm
  • Range
    Up to 80 meters
Battery
  • Model
    CR2016*1
  • Capacity
    80mAh
  • Operating Temperature
    -20°C to +60°C (Battery limit)
  • Expected life
    3 months by default
Service
  • Warranty
    1 year
Construction
  • Material
    TPU, in line with FDA regulation
  • Dimensions
    250×36×4.2mm
  • Weight
    8.0g
  • Color
    White
Features
  • Wristband
    Disposable Cut-off Alert wristband
  • Waterproof grade
    IP67
  • Power on/off
    Built-in press button
Ci - S07 單向
Protocol Options
  • iBeacon
    YES
  • Eddystone
    YES
  • NFC
    Available
Features
  • Flexible Wearable Type
    Neck-string or key-chain for option
  • Lightweight
    Portable and comfortable
  • Quick Start
    Take out the battery sheet from beacon easily
Compatibility
  • Wireless Compatibility
    Bluetooth low-energy 4.1and 5.0
  • Compatible Systems
    iOS 7.0 or above, Android 4.3 or above
  • Protocols
    iBeacon, Eddystone (UID, URL, TLM)
Physical Character
  • Color
    White, other colors can be customized
  • Dimensions
    42.3mm x 31mm x 11mm
  • Weight
    20.0 g
  • Battery
    One replaceable, CR2032
Radio
  • Beacon Interval
    Configurable 100ms to 5 second
  • Transmit Power
    -40dBm to 4dBm configurable
  • Signal Range
    50 meters
Verification
  • Estimated Operational Life
    1 year with a 0dBm 900ms iBeacon interval
  • Environment Resistance
    Indoor environment, shock resistant
  • Environment Resistance
    iBeacon MFi License, CE, FCC, Bluetooth QDID/EPL
Ci - G1 Gateway
Specification
  • 經由920MHz與標籤通訊
  • 單台最多支援1000個標籤
  • 經由Wifi/有線連接網路
  • 處理能力:60個標籤/秒
  • 支援PoE供電
  • 支援無縫漫遊
  • 發射功率:20dbm
  • 邊緣運算架構
  • 4G/5G數據回傳
  • 支援Master/Slave模式
  • 室內覆蓋半徑:30~50公尺
Ci - G2 Gateway
Specification
  • 處理器
    • 第 8 代 Intel® Core™ i7 處理器
    • 第 8 代 Intel® Core™ i5 處理器
    • 第 8 代 Intel® Core™ i3 處理器
  • 作業系統
    • Windows 10 專業版 64 位元 - Lenovo 推薦商務用 Windows 10 專業版
    • Windows 10 家用版 64 位元
  • 記憶體
    最高搭載 2 GB DDR4 記憶體
  • 儲存裝置
    2.5 吋 HDD 或 PCIe 附加記憶卡
  • 顯示卡
    Intel® Integrated Graphics 630
  • 擴充槽
    • 1 個 M.2 SSD 或 Intel® Optane™
    • 1 個 M.2 WiFi
  • 外置機糟
    光碟機 (需另行購買)
  • 電源
    • 65 W 88% 變壓器
    • 90 W 88% 變壓器 (i7 處理器專用)
    • 135 W 88% 變壓器
  • 尺寸 (高 x 寬 x 深)
    179 毫米 x 36.5 毫米 x 182.9 毫米 / 7.0 吋 x 1.4 吋 x 7.2 吋
  • 重量
    重量由 1.32 公斤 / 2.91 磅起
  • 連線功能
    • 802.11ac 1x1 + Bluetooth® 4.0
    • 802.11ac 2x2 + Bluetooth® 4.0
  • 正面連接埠
    • USB 3.1 第 2 代 (最高搭載 10 Gbps 數據傳輸功能)
    • USB 3.1 第 1 代 C 型 (最高搭載 5 Gbps 數據傳輸功能)
    • 複合埠 + 麥克風
    • 耳機/麥克風複合插孔
  • 背面連接埠
    • USB 3.1 第 2 代 (最高搭載 10 Gbps 數據傳輸功能)
    • USB 3.1 第 1 代 (最高搭載 5 Gbps 數據傳輸功能)
    • DisplayPort™ + HDMI™
    • 序列埠、第 2 個另購序列埠
    • 2 個接駁口 (序列埠/DP/HDMI/C 型 + DP/VGA)
    • 1 個 LAN
警示燈與蜂鳴器控制模組
Specification
  • Processor
    Broadcom BCM2711, Quad core Cortex-A72(ARM v8) 64-bit SoC @ 1.5GHz
  • Controllable device
    Red LED or Yellow LED or Green LED or Buzzer (Continuous / Flash times control)
  • Communication protocol
    http / https API
  • Network Type
    Wired network or Wireless network
  • Power supply
    5V / 3A DC via USB-A connector
  • Tricolor Light connector
    RJ-45
  • Size
    15.5 mm x 17 mm x 5 mm
硬體設備
Hardware Facilities
整合圖臺
Software System
  • Beacon 定位與 UWB 定位在圖台上使用同1套向量圖資。
  • 可整合市面上不同 Beacon 與 UWB 硬體訊號。
  • 即時接受主動式、被動式回傳電量之資訊,統計各硬體即時耗電量。
  • 監控硬體傳送數據狀態,並將設備狀態資訊顯示於圖台。
  • 即時監控由管理者所框選的特定警戒區域,並在螢幕上顯示警示訊息。
  • 彙整使用者定位數據,提供熱點圖、停留時間與使用者軌跡。
  • 即時定位地圖通用於主流瀏覽器、Android 與 iOS 等系統。
應用服務
Application Services
UWB
  • 資產盤點
    資產盤點
    適用於醫院、製造業、物流業...等領域,進行即時盤點作業,搭配電子圍籬可監控特定區域之資產資訊。
  • 人員定位
    人員定位
    提升人力效值、降低工安意外(人員工安管理、承攬商定位管理)
  • 物料管理
    物料管理
    自走車定位、倉儲物流配送管理。
  • 環控管理
    環控管理
    關燈工廠應用、空調能源管理、攝影機管理、空氣品質監測。
BLE
  • App 導航
    App 導航
    搭配 Beacon 導航技術,適用機場、醫院、博物館...等領域。
  • App 自主推播導覽
    App 自主推播導覽
    適用於商場與博物館,進行相關產品或展品資訊推播。
  • 停車場尋車導航
    停車場尋車導航
    結合車牌辨識系統,提供民眾室內尋車導航。
相關報導
Press Release
X
